AD9862BSTRL image
Favorite
AD9862BSTRL image
Favorite
RoHS
/
Package 128-LQFP
Category RF/IF and RFID / RF Front End (LNA + PA)
Description BASEBAND TRANSCEIVER FOR B/BAND
PDF
/
Buying Options
Total Price: USD $44.48
Unit Price: USD $44.484
≥1 USD $44.484
Inventory: 2014
Minimum: 1
-
+

Technical Details

Physical

Package / Case 128-LQFP
Surface Mount YES

Technical

Packaging Tape & Reel (TR)
JESD-609 Code e0
Feature 12-Bit ADC(s), 14-Bit DAC(s)
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 128
Terminal Finish TIN LEAD
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 128
JESD-30 Code R-PQFP-G128
Qualification Status COMMERCIAL
Operating Temperature (Max) 70°C
Operating Temperature (Min) -40°C
Temperature Grade OTHER
Telecom IC Type TELECOM CIRCUIT
RF Type LMDS, MMDS

Dimensions

Height Seated (Max) 1.6mm
Length 20mm
Width 14mm

Compliance

RoHS Status Non-RoHS Compliant
