MAX2742ECM+D
RoHS
RoHS compliant
RoHS compliantPackage 48-TQFP Exposed Pad
Category RF/IF and RFID / RF Front End (LNA + PA)
Description
IC GPS RF FRONT END 48TQFP
PDF
/
Inventory: 2757
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Front
Package / Case 48-TQFP Exposed Pad
Technical
Packaging Tray
Published 2008
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 48
ECCN Code 7A994
Terminal Finish Tin (Sn)
HTS Code 8542.39.00.01
Technology CMOS
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3V
Terminal Pitch 0.5mm
Frequency 1575.42MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 48
JESD-30 Code S-XQCC-N48
Qualification Status Not Qualified
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Supply Voltage-Max (Vsup) 3.6V
Temperature Grade INDUSTRIAL
Supply Voltage-Min (Vsup) 2.4V
RF Type GPS
Response BANDPASS
Active Filter Type SWITCHED CAPACITOR FILTER
Dimensions
Height Seated (Max) 1mm
Length 7mm
Width 7mm
Compliance
RoHS Status ROHS3 Compliant
