BPF2012LM09R2400A
RoHS
/
Package 0805 (2012 Metric), 4 PC Pad
Category Filters / RF Filters
Description
Signal Conditioning 2.45GHz BAND PASS FILTER
PDF
/
Inventory: 9705
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0805 (2012 Metric), 4 PC Pad
Technical
Packaging Tape & Reel (TR)
Published 2013
Series 2012
Size / Dimension 0.079Lx0.049W 2.00mmx1.25mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Frequency 2.45GHz Center
Case Code (Imperial) 0805
Impedance 50Ohm
Filter Type Band Pass
Insertion Loss (dB) 1.2 dB
Ripple 0.6dB
Dimensions
Height 1.0414mm
Compliance
RoHS Status RoHS Compliant
