ELB-2A004 image
Favorite
RoHS
/
Package 0805 (2012 Metric), 4 PC Pad
Category Filters / RF Filters
Description FILTER BAND PASS 4.9GHZ SMD
PDF
/
Buying Options
Total Price: USD $1.79
Unit Price: USD $1.789483
≥1 USD $1.789483
≥200 USD $0.714218
≥500 USD $0.690585
≥1000 USD $0.678769
Inventory: 4271
Minimum: 1
-
+

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0805 (2012 Metric), 4 PC Pad

Technical

Packaging Tape & Reel (TR)
Published 2005
Series ELB2A
Size / Dimension 0.079Lx0.049W 2.00mmx1.25mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2 (1 Year)
Frequency 4.885GHz Center
Case Code (Metric) 2012
Case Code (Imperial) 0805
Bandwidth 125MHz
Filter Type Band Pass
Insertion Loss 2.5dB
Insertion Loss (dB) 2.5 dB
Ripple 1dB

Dimensions

Height 1.2954mm
Length 2.0066mm
Width 1.2446mm
Height (Max) 0.051 1.30mm

Compliance

RoHS Status RoHS Compliant
Lead Free Lead Free
