ELB-2A002
RoHS
/
Package 0805 (2012 Metric), 4 PC Pad
Category Filters / RF Filters
Description
FILTER BAND PASS 5.5GHZ SMD
PDF
/
Buying Options
Total Price: USD $0.54
Unit Price: USD $0.5377
≥1 USD $0.5377
≥10 USD $0.4408
≥100 USD $0.4275
≥500 USD $0.41325
≥1000 USD $0.39995
Inventory: 3008
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Height (Max) 0.051 1.30mm
Width 1.2446mm
Length 2.0066mm
Height 1.2954mm
Technical
Ripple 1dB
Insertion Loss (dB) 1.5 dB
Insertion Loss 1.5dB
Filter Type Band Pass
Bandwidth 700MHz
Case Code (Imperial) 0805
Case Code (Metric) 2012
Frequency 5.5GHz Center
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Size / Dimension 0.079Lx0.049W 2.00mmx1.25mm
Series ELB2A
Published 2005
Packaging Tape & Reel (TR)
Physical
Package / Case 0805 (2012 Metric), 4 PC Pad
Mounting Type Surface Mount
Mount Surface Mount
