LFD21859MDP2A076
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric), 8 PC Pad
Category Filters / RF Filters
Description
RF FILTER SIGNAL CONDITION 0805
PDF
/
Buying Options
Total Price: USD $6.02
Unit Price: USD $6.0192
≥1 USD $6.0192
≥10 USD $4.93905
≥100 USD $4.7842
≥500 USD $4.6303
≥1000 USD $4.47545
Inventory: 1533
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height (Max) 0.041 1.05mm
Width 1.25mm
Length 2mm
Technical
Receive Center Frequency 1920MHz
Insertion Loss (Rx) 0.45 dB
Insertion Loss (Tx) 0.4 dB
Filter Type DUPLEXER
Physical Dimension L2.0XB1.25XH0.9 (mm)/L0.079XB0.049XH0.035 (inch)
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin (Sn)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Size / Dimension 0.079Lx0.049W 2.00mmx1.25mm
Packaging Tape & Reel (TR)
Physical
Number of Pins 8
Package / Case 0805 (2012 Metric), 8 PC Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
