LFD212G45DP4A189
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric), 8 PC Pad
Category Filters / RF Filters
Description
RF FILTER SIGNAL CONDITION 0805
PDF
/
Buying Options
Total Price: USD $0.14
Unit Price: USD $0.1387
≥1 USD $0.1387
≥10 USD $0.114
≥100 USD $0.1102
≥500 USD $0.1064
≥1000 USD $0.10355
Inventory: 3658
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Surface Mount
Package / Case 0805 (2012 Metric), 8 PC Pad
Number of Pins 8
Technical
Packaging Tape & Reel (TR)
Size / Dimension 0.079Lx0.049W 2.00mmx1.25mm
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Tin (Sn)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Physical Dimension L2.0XB1.25XH0.9 (mm)/L0.079XB0.049XH0.035 (inch)
Filter Type DUPLEXER
Insertion Loss (Tx) 0.5 dB
Insertion Loss (Rx) 0.75 dB
Transmit Center Frequency 2450MHz
Receive Center Frequency 5375MHz
Dimensions
Length 2mm
Width 1.25mm
Height (Max) 0.039 1.00mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
