MACP-009011-C80370
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD Module
Category RF/IF and RFID / RF Directional Coupler
Description
RF DIR COUPLER 5MHZ-1.2GHZ 6SMD
PDF
/
Buying Options
Total Price: USD $4.1
Unit Price: USD $4.1008
≥1 USD $4.1008
≥10 USD $3.32112
≥100 USD $2.685056
≥500 USD $2.515568
≥1000 USD $2.4024
≥3000 USD $2.331754
Inventory: 769
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Coupling Factor 8dB
Coupler Type Standard
Return Loss 18.5dB
Characteristic Impedance 75Ohm
Input Power-Max (CW) 23.98dBm
RF/Microwave Device Type DIRECTIONAL COUPLER
Operating Temperature (Min) -20°C
Operating Temperature (Max) 85°C
Frequency 5MHz~1.2GHz
Max Power Dissipation 250mW
Applications General Purpose
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2009
Packaging Tape & Reel (TR)
Physical
Package / Case 6-SMD Module
Supply Chain
Factory Lead Time 10 Weeks
