1748CF15A075E
RoHS
/
Package 0805 (2012 Metric)
Category RF/IF and RFID / RF Directional Coupler
Description
DIR COUPLER W/LP FILTER 1748MHZ
PDF
/
Inventory: 4423
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Coupling Factor 20 ± 1dB
Coupler Type Standard
Return Loss 14dB
Insertion Loss (dB) 0.5 dB
Isolation 25dB
Insertion Loss 0.5dB
Power - Max 3W
Impedance 50Ohm
Case Code (Imperial) 0805
Case Code (Metric) 2012
Frequency 1.71GHz~1.785GHz
Max Power Dissipation 3W
Composition Ceramic
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2001
Packaging Cut Tape (CT)
Physical
Supplier Device Package 0805
Package / Case 0805 (2012 Metric)
