XC2100A-30S
RoHS
RoHS compliant
RoHS compliantPackage 4-SMD, No Lead
Category RF/IF and RFID / RF Directional Coupler
Description
RF Couplers Uni-directional Coupling 31dB 1.805GHz to 2.3GHz 4-Pin CSMD T/R
PDF
/
Buying Options
Total Price: USD $6.2
Unit Price: USD $6.1952
≥1 USD $6.1952
≥10 USD $5.53256
≥100 USD $4.979392
≥500 USD $4.53684
≥1000 USD $4.094253
≥3000 USD $3.673771
Inventory: 1097
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Coupling Factor 30dB
Coupler Type Standard
Characteristic Impedance 50Ohm
Input Power-Max (CW) 50.79dBm
Insertion Loss (dB) 0.15 dB
VSWR-Max 1.22
RF/Microwave Device Type DIRECTIONAL COUPLER
Power - Max 120W
Operating Temperature (Min) -55°C
Operating Temperature (Max) 95°C
Frequency 2GHz~2.3GHz
Construction COMPONENT
Max Power Dissipation 120W
HTS Code 8517.70.00.00
Applications General Purpose
Terminal Finish Tin (Sn)
ECCN Code 5A991.G
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Xinger II?
Published 2010
Packaging Tape & Reel (TR)
Physical
Number of Pins 4
Package / Case 4-SMD, No Lead
Supply Chain
Factory Lead Time 12 Weeks
