X3C30F1-20S
RoHS
/
Package 4-SMD, No Lead
Category RF/IF and RFID / RF Directional Coupler
Description
RF DIR COUPLER 2GHZ-4GHZ SMD
PDF
/
Buying Options
Total Price: USD $4
Unit Price: USD $4.004
≥1 USD $4.004
≥10 USD $3.5772
≥100 USD $3.219744
≥500 USD $2.93348
≥1000 USD $2.647286
≥3000 USD $2.375402
Inventory: 1171
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Package / Case 4-SMD, No Lead
Technical
Packaging Tape & Reel (TR)
Published 2017
Series Xinger III?
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Tin (Sn) - immersion
Applications Cellular
Construction COMPONENT
Frequency 2GHz~4GHz
Operating Temperature (Max) 140°C
Operating Temperature (Min) -55°C
Power - Max 25W
RF/Microwave Device Type DIRECTIONAL COUPLER
Insertion Loss 0.075dB
Isolation 27dB
VSWR-Max 1.22
Input Power-Max (CW) 43.98dBm
Characteristic Impedance 50Ohm
Coupler Type Standard
Coupling Factor 20dB ± 1.5dB
Compliance
RoHS Status Non-RoHS Compliant
