X3C19E2-20S
RoHS
RoHS compliant
RoHS compliantPackage 4-SMD, No Lead
Category RF/IF and RFID / RF Directional Coupler
Description
COUPLER 90DEG 1700-2000MHZ 20DB
PDF
/
Buying Options
Total Price: USD $6.15
Unit Price: USD $6.1512
≥1 USD $6.1512
≥10 USD $5.48856
≥100 USD $4.939616
≥500 USD $4.500408
≥1000 USD $4.061376
≥3000 USD $3.644256
Inventory: 1947
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Package / Case 4-SMD, No Lead
Number of Pins 4
Technical
Packaging Tape & Reel (TR)
Published 2007
Series Xinger III?
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Max Operating Temperature 95°C
Min Operating Temperature -55°C
Applications DCS, PCS, WCDMA
Max Power Dissipation 225W
Construction COMPONENT
Frequency 1.4GHz~2.7GHz
RF/Microwave Device Type DIRECTIONAL COUPLER
VSWR-Max 1.22
Insertion Loss (dB) 0.1 dB
Input Power-Max (CW) 53.01dBm
Characteristic Impedance 50Ohm
Return Loss 24.9dB
Coupler Type Standard
Coupling Factor 20.3dB
Compliance
RoHS Status RoHS Compliant
