X3C17A1-03WS
RoHS
RoHS compliant
RoHS compliantPackage 4-SMD, No Lead
Category RF/IF and RFID / RF Directional Coupler
Description
RF DIR COUPLER 690MHZ-2.7GHZ SMD
PDF
/
Buying Options
Total Price: USD $9.26
Unit Price: USD $9.2576
≥1 USD $9.2576
≥10 USD $8.48584
≥100 USD $7.714784
≥500 USD $6.943288
≥1000 USD $6.364688
≥3000 USD $5.786088
Inventory: 3262
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Coupler Type Standard
Characteristic Impedance 50Ohm
Insertion Loss (dB) 0.49 dB
VSWR-Max 1.33
Isolation 20dB
RF/Microwave Device Type 90 DEGREE HYBRID COUPLER
Frequency 690MHz~2.7GHz
Construction COMPONENT
Max Power Dissipation 50W
Additional Feature HIGH ISOLATION
Applications General Purpose
Min Operating Temperature -55°C
Max Operating Temperature 95°C
Terminal Finish Tin (Sn)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series Xinger III?
Published 2012
Packaging Tape & Reel (TR)
Physical
Number of Pins 4
Package / Case 4-SMD, No Lead
Supply Chain
Factory Lead Time 12 Weeks
