1J0280-3

Anaren
RoHS
/
Package 100
Category RF/IF and RFID / RF Directional Coupler
Description RF DIR COUPLER 100MHZ-160MHZ
PDF
/
Inventory: 974
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Technical

Coupling Factor 3dB
Coupler Type Standard
Return Loss 20.8dB
Characteristic Impedance 50Ohm
Input Power-Max (CW) 56.99dBm
VSWR-Max 1.2
Isolation 20dB
Insertion Loss 0.3dB
RF/Microwave Device Type 90 DEGREE HYBRID COUPLER
Power - Max 500W
Frequency 100MHz~160MHz
Construction MODULE
Applications Military
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2001
Packaging Tray

Physical

Package / Case 100

Supply Chain

Factory Lead Time 8 Weeks
