MAX4003EBL+T
RoHS
RoHS compliant
RoHS compliantPackage 8-UFBGA, WLCSP
Category RF/IF and RFID / RF Detectors
Description
Tape & Reel (TR) 1 Surface Mount Cellular TDMA CDMA GPRS GSM RF Detector IC 1.52mm -45dBm-0dBm 3V 100MHz~2.5GHz
PDF
/
Buying Options
Total Price: USD $0.93
Unit Price: USD $0.9291
≥1 USD $0.9291
≥10 USD $0.76285
≥100 USD $0.7391
≥500 USD $0.71535
≥1000 USD $0.6916
Inventory: 1187
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 8-UFBGA, WLCSP
Surface Mount YES
Technical
Packaging Tape & Reel (TR)
Published 2007
JESD-609 Code e1
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
HTS Code 8542.39.00.01
Technology CMOS
Voltage - Supply 2.7V~5V
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3V
Terminal Pitch 0.5mm
Frequency 100MHz~2.5GHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 8
JESD-30 Code S-PBGA-B8
Qualification Status Not Qualified
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Temperature Grade INDUSTRIAL
Current - Supply 5.9mA
Telecom IC Type RF AND BASEBAND CIRCUIT
RF Type Cellular, TDMA, CDMA, GPRS, GSM
Input Range -45dBm ~ 0dBm
Dimensions
Height Seated (Max) 0.67mm
Length 1.52mm
Width 1.52mm
Compliance
RoHS Status ROHS3 Compliant
