MAX4002EUA-T
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category RF/IF and RFID / RF Detectors
Description
Tape & Reel (TR) 1 Surface Mount Cellular CDMA GSM RF Detector IC 3mm -30dBm-15dBm 3V 100MHz~2.5GHz
PDF
/
Buying Options
Total Price: USD $3.03
Unit Price: USD $3.03335
≥1 USD $3.03335
≥10 USD $2.489
≥100 USD $2.4111
≥500 USD $2.33415
≥1000 USD $2.25625
Inventory: 29003
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3mm
Length 3mm
Height Seated (Max) 1.1mm
Technical
Input Range -30dBm ~ 15dBm
RF Type Cellular, CDMA, GSM
Supply Current-Max (Isup) 9.3mA
Bandwidth 2400MHz
Current - Supply 5.9mA
Analog IC - Other Type LOG OR ANTILOG AMPLIFIER
Supply Voltage-Min (Vsup) 2.7V
Temperature Grade INDUSTRIAL
Power Supplies 3V
Supply Voltage-Max (Vsup) 5.5V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Qualification Status Not Qualified
JESD-30 Code S-PDSO-G8
Pin Count 8
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 100MHz~2.5GHz
Reach Compliance Code not_compliant
Terminal Pitch 0.65mm
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 245
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.7V~5.5V
Technology BIPOLAR
Subcategory Analog Computational Functions
HTS Code 8542.39.00.01
Terminal Finish Tin/Lead (Sn85Pb15)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Published 2008
Packaging Tape & Reel (TR)
Physical
Surface Mount YES
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
