MAX2014EUA+
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category RF/IF and RFID / RF Detectors
Description
50MHz to 1000MHz, 75dB Logarithmic Detector/Controller
PDF
/
Buying Options
Total Price: USD $6.14
Unit Price: USD $6.1424
≥1 USD $6.1424
≥10 USD $5.54752
≥100 USD $5.289856
≥500 USD $4.59316
≥1000 USD $4.542982
Inventory: 512
Minimum: 1
-
+
Technical Details
Technical
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 2.7V~5.25V
Technology BICMOS
Max Power Dissipation 362mW
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2012
Packaging Tube
Input Range -65dBm ~ 5dBm
RF Type Cellular, GSM, EDGE, CDMA
Element Configuration Single
Operating Supply Current 20.5mA
Analog IC - Other Type ANALOG CIRCUIT
Supply Voltage-Min (Vsup) 2.7V
Temperature Grade INDUSTRIAL
Supply Voltage-Max (Vsup) 3.6V
Base Part Number MAX2014
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 50MHz~1GHz
Terminal Pitch 0.65mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Physical
Number of Pins 8
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 3mm
Length 3mm
