LTC5587IDD
RoHS
/
Package 12-WFDFN Exposed Pad
Category RF/IF and RFID / RF Detectors
Description
IC RF DETECT 10MHZ-6GHZ 12DFN
PDF
/
Buying Options
Total Price: USD $18.39
Unit Price: USD $18.38725
≥1 USD $18.38725
≥10 USD $15.08695
≥100 USD $14.61575
≥500 USD $14.1436
≥1000 USD $13.6724
Inventory: 696
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 12-WFDFN Exposed Pad
Surface Mount YES
Technical
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 12
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
HTS Code 8542.39.00.01
Technology CMOS
Voltage - Supply 2.7V~3.6V
Terminal Position DUAL
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 0.45mm
Frequency 10MHz~6GHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 12
JESD-30 Code S-PDSO-N12
Qualification Status Not Qualified
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Temperature Grade INDUSTRIAL
Accuracy ±1dB
Current - Supply 3mA
Telecom IC Type TELECOM CIRCUIT
RF Type CDMA, GSM, EDGE, W-CDMA
Input Range -34dBm ~ 6dBm
Dimensions
Height Seated (Max) 0.8mm
Length 3mm
Width 3mm
Compliance
RoHS Status Non-RoHS Compliant
