LTC5530ES6#TRMPBF
RoHS
RoHS compliant
RoHS compliantPackage SOT-23-6 Thin, TSOT-23-6
Category RF/IF and RFID / RF Detectors
Description
IC RF DETECT 300MHZ-7GHZ TSOT23
PDF
/
Buying Options
Total Price: USD $4.41
Unit Price: USD $4.4088
≥1 USD $4.4088
≥10 USD $3.9556
≥100 USD $3.739648
≥500 USD $3.24104
≥1000 USD $3.07479
Inventory: 1277
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 1.75mm
Length 2.9mm
Height 900μm
Technical
Input Range -32dBm ~ 10dBm
RF Type 802.11a/b/g/WiFi, 802.16/WiMax, WLAN
Nominal Supply Current 500μA
Operating Supply Current 500μA
Analog IC - Other Type ANALOG CIRCUIT
Supply Voltage-Min (Vsup) 2.7V
Temperature Grade INDUSTRIAL
Supply Voltage-Max (Vsup) 6V
Qualification Status Not Qualified
Pin Count 6
Base Part Number LTC5530
Time@Peak Reflow Temperature-Max (s) 30
Frequency 300MHz~7GHz
Terminal Pitch 0.95mm
Supply Voltage 3.6V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.7V~6V
HTS Code 8542.39.00.01
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2004
Packaging Tape & Reel (TR)
Physical
Number of Pins 6
Package / Case SOT-23-6 Thin, TSOT-23-6
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 week ago)
Factory Lead Time 8 Weeks
