LT5534ESC6#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage 6-VSSOP, SC-88, SOT-363
Category RF/IF and RFID / RF Detectors
Description
IC RF DETECT 50MHZ-3GHZ SC70-6
PDF
/
Buying Options
Total Price: USD $11.57
Unit Price: USD $11.572
≥1 USD $11.572
≥10 USD $10.63568
≥100 USD $10.194624
≥500 USD $8.982248
≥1000 USD $8.54135
≥3000 USD $7.990312
Inventory: 8031
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Input Range -63dBm ~ -3dBm
Characteristic Impedance 50Ohm
RF Type Broadcast Television
RF/Microwave Device Type LINEAR DETECTOR
Accuracy ±1dB
Nominal Supply Current 7mA
Operating Supply Current 9mA
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Pin Count 6
Base Part Number LT5534
Frequency 50MHz~3GHz
Construction COMPONENT
Voltage - Supply 2.7V~5.25V
Terminal Finish MATTE TIN
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2010
Packaging Tape & Reel (TR)
Physical
Number of Pins 6
Package / Case 6-VSSOP, SC-88, SOT-363
Mounting Type Surface Mount
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 4 months ago)
Factory Lead Time 10 Weeks
