ADL5504ACBZ-P2
RoHS
RoHS compliant
RoHS compliantPackage 6-WFBGA, WLCSP
Category RF/IF and RFID / RF Detectors
Description
Tape & Reel (TR) ADL5504 TruPwr? Surface Mount RF Detector IC -25dB-15dB ±0.25dB 450MHz~6GHz 50Ohm
PDF
/
Buying Options
Total Price: USD $8.3
Unit Price: USD $8.2954
≥1 USD $8.2954
≥10 USD $6.80675
≥100 USD $6.59395
≥500 USD $6.38115
≥1000 USD $6.16835
Inventory: 506
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 6-WFBGA, WLCSP
Number of Pins 6
Technical
Packaging Tape & Reel (TR)
Series TruPwr?
JESD-609 Code e1
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Voltage - Supply 2.5V~3.3V
Construction COMPONENT
Frequency 450MHz~6GHz
Base Part Number ADL5504
Operating Supply Current 1.8mA
Accuracy ±0.25dB
RF/Microwave Device Type LINEAR DETECTOR
RF Type CDMA, QPSK, W-CDMA
Characteristic Impedance 50Ohm
Input Range -25dB ~ 15dB
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
