SRF-1016
RoHS
/
Package 16-TSSOP (0.173, 4.40mm Width)
Category RF/IF and RFID / RF Demodulators
Description
RF DEMOD IC 65MHZ-300MHZ 16TSSOP
PDF
/
Buying Options
Total Price: USD $9.4
Unit Price: USD $9.3974
≥1 USD $9.3974
≥10 USD $7.7102
≥100 USD $7.46985
≥500 USD $7.22855
≥1000 USD $6.9882
Inventory: 39
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Surface Mount YES
Technical
Packaging Tape & Reel (TR)
Published 2010
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Terminal Finish TIN LEAD
HTS Code 8542.39.00.01
Voltage - Supply 4.75V~5.25V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 5V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDSO-G16
Function Demodulator, Receiver
Qualification Status Not Qualified
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Temperature Grade INDUSTRIAL
Operating Supply Current 195mA
Logic Function Receiver
Telecom IC Type BASEBAND CIRCUIT
Noise Figure 31dB
P1dB 31dBm
RF Frequency 65MHz~300MHz
LO Frequency 65MHz~300MHz
Dimensions
Height Seated (Max) 1.2mm
Length 5.075mm
Width 4.4mm
Compliance
RoHS Status Non-RoHS Compliant
