LTC5585IUF#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage 24-WFQFN Exposed Pad
Category RF/IF and RFID / RF Demodulators
Description
RF DEMOD IC 400MHZ-4GHZ 24QFN
PDF
/
Buying Options
Total Price: USD $21.48
Unit Price: USD $21.47855
≥1 USD $21.47855
≥10 USD $17.62345
≥100 USD $17.07245
≥500 USD $16.5224
≥1000 USD $15.9714
Inventory: 4705
Minimum: 1
-
+
Technical Details
Technical
P1dB 16dBm
RF Frequency 400MHz~4GHz
LO Frequency 400MHz~4GHz
Noise Figure 13.5dB
Gain 2.4dB
Supply Current-Max 0.22mA
Operating Supply Current 200mA
Temperature Grade INDUSTRIAL
Power Supplies 5V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 105°C
Qualification Status Not Qualified
Function Demodulator
Base Part Number LTC5585
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 4.75V~5.25V
Technology CMOS
Subcategory Other Telecom ICs
HTS Code 8542.39.00.01
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2012
Packaging Tape & Reel (TR)
Dimensions
Height Seated (Max) 0.8mm
Length 4mm
Width 4mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Number of Pins 24
Surface Mount YES
Package / Case 24-WFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
Factory Lead Time 16 Weeks
