LT5546EUF#PBF
RoHS
RoHS compliant
RoHS compliantPackage 16-WQFN Exposed Pad
Category RF/IF and RFID / RF Demodulators
Description
RF DEMOD IC 40MHZ-500MHZ 16QFN
PDF
/
Buying Options
Total Price: USD $6.96
Unit Price: USD $6.9608
≥1 USD $6.9608
≥10 USD $6.28672
≥100 USD $5.204866
≥500 USD $5.148
Inventory: 1458
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Modulation Technique I/Q
LO Frequency 80MHz~1GHz
RF Frequency 40MHz~500MHz
P1dB -10dBm
Noise Figure 7.8dB
Operating Frequency-Min 40MHz
Operating Frequency-Max 500MHz
Current - Supply 24mA
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Function Demodulator
Base Part Number LT5546
Construction COMPONENT
Voltage - Supply 1.8V~5.25V
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2005
Packaging Tube
Physical
Package / Case 16-WQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 20 Weeks
