PC29.07.0100A
RoHS
RoHS compliant
RoHS compliantPackage /
Category RF/IF and RFID / RF Antennas
Description
RF ANT 850MHZ/900MHZ FLAT PATCH
PDF
/
Buying Options
Total Price: USD $10.91
Unit Price: USD $10.912
≥1 USD $10.912
≥10 USD $7.0136
≥100 USD $6.2304
≥500 USD $5.522
Inventory: 230
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height (Max) 0.031 0.80mm
Width 30mm
Length 80mm
Height 787.4μm
Technical
Return Loss -13dB, -11dB, -14dB, -16dB, -16dB
Frequency (Center/Band) 850MHz 900MHz 1.8GHz 1.9GHz 2.1GHz
Frequency Group UHF 300MHz~1GHz UHF 1GHz~2GHz
Number of Bands 5
VSWR 1.58, 1.78, 1.51, 1.38, 1.37
Antenna Type Flat Patch
RF Family/Standard Cellular
Max Frequency 2.1GHz
Gain 0.01dBi, 1.2dBi, 2.66dBi, 1.25dBi, 1.43dBi
Impedance 50Ohm
Frequency 2.1GHz
Applications CDMA, GSM, UMTS
Termination U.FL (UMCC), IPEX MHF1
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series TheStripe?
Packaging Bulk
Physical
Mounting Type Adhesive
Mount Adhesive
Supply Chain
Factory Lead Time 8 Weeks
