PA.700.A
RoHS
RoHS compliant
RoHS compliantPackage SMD/SMT
Category RF/IF and RFID / RF Antennas
Description
EMBEDDED CELLUAR SMT ANT
PDF
/
Buying Options
Total Price: USD $13.24
Unit Price: USD $13.244
≥1 USD $13.244
≥10 USD $10.128888
Inventory: 912
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SMD/SMT
Technical
Packaging Tape & Reel (TR)
Series Viking
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Termination Solder
Applications CDMA, DCS, EDGE, GPRS, GSM, HSDPA, LTE, PCS, UMTS, WCDMA
Frequency 2.1GHz
Impedance 50Ohm
Gain 2dBi, 1.4dBi, 0.9dBi, 3.7dBi, 3.9dBi, 4.1dBi
Frequency Range 700MHz~960MHz 1.71GHz~2.17GHz
RF Family/Standard Cellular
Antenna Type Chip
VSWR 3
Number of Bands 6
Frequency Group Wide B
Frequency (Center/Band) 700MHz 850MHz 900MHz 1.8GHz 1.9GHz 2.1GHz
Dimensions
Height 5.0038mm
Length 40mm
Width 6mm
Height (Max) 0.197 5.00mm
Compliance
RoHS Status ROHS3 Compliant
