AH104F2450S1-T
RoHS
RoHS compliant
RoHS compliantPackage SMD/SMT
Category RF/IF and RFID / RF Antennas
Description
ANT BLUETOOTH W-LAN ZIGBEE WIMAX
PDF
/
Buying Options
Total Price: USD $5.51
Unit Price: USD $5.5088
≥1 USD $5.5088
≥10 USD $4.95
≥100 USD $4.679488
≥500 USD $4.055568
≥1000 USD $3.847606
≥3000 USD $3.452451
Inventory: 1164
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 4mm
Length 10mm
Height 990.6μm
Technical
Omnidirectional NO
Frequency (Center/Band) 2.4GHz
Frequency Group UHF 2GHz~3GHz
Number of Bands 1
VSWR 3
Antenna Type Chip
RF Family/Standard 802.15.4, Bluetooth, WiFi
RF/Microwave Device Type ANTENNA-OTHER
Frequency Range 2.4GHz~2.5GHz
Gain 1.7dBi
Impedance 50Ohm
Polarization LINEAR HORIZONTAL/LINEAR VERTICAL
Frequency 2.45GHz
Construction COMPONENT
Applications Bluetooth, WLAN, Zigbee?
Min Operating Temperature -20°C
Max Operating Temperature 80°C
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2010
Packaging Tape & Reel (TR)
Physical
Number of Pins 8
Package / Case SMD/SMT
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 13 Weeks
