2066400001
RoHS
RoHS compliant
RoHS compliantPackage /
Category RF/IF and RFID / RF Antennas
Description
GNSS Active Patch Antenna with Low-Noise Amplifier (LNA)
PDF
/
Buying Options
Total Price: USD $10
Unit Price: USD $9.9968
≥1 USD $9.9968
≥10 USD $9.02968
≥100 USD $8.609392
≥500 USD $7.475424
≥1000 USD $7.13944
≥3000 USD $6.509474
Inventory: 1166
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mounting Type Adhesive
Technical
Series 206640
Feature LNA
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination U.FL (UMCC), IPEX MHF1
Applications Beidou, Galileo, GLONASS, GPS
Additional Feature IT CAN ALSO OPERATE AT 1572 TO 1578 AND 1597 TO 1607 MHZ
Construction MODULE
Polarization RHCP
Gain 4.5dBi
RF/Microwave Device Type GPS ANTENNA
Operating Frequency-Max 1564MHz
RF Family/Standard Navigation
Antenna Type Ceramic Patch
Operating Frequency-Min 1558MHz
Number of Bands 3
Frequency Group Wide B
Frequency (Center/Band) 1.561GHz 1.575GHz 1.602GHz
Characteristic Impedance 50Ohm
Return Loss -8dB
Dimensions
Height (Max) 0.256 6.50mm
Compliance
RoHS Status RoHS Compliant
