ANT-DB1-NSP250-T
RoHS
RoHS compliant
RoHS compliantPackage /
Category RF/IF and RFID / RF Antennas
Description
RF ANT 2.4GHZ 5.8GHZ CHIP SOLDER
PDF
/
Buying Options
Total Price: USD $1.6
Unit Price: USD $1.596486
≥1 USD $1.596486
≥200 USD $0.638069
≥500 USD $0.61575
≥1000 USD $0.605247
Inventory: 1097
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Surface Mount
Technical
Packaging Tape & Reel (TR)
Series nanoSplatch?
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Applications Bluetooth, Wi-Fi, WLAN, Zigbee?, 802.11, U-NII
Power - Max 5W
Gain 2.7dBi, 3.7dBi
Frequency Range 2.4GHz~2.5GHz 5.15GHz~5.88GHz
RF Family/Standard Bluetooth, WiFi
Antenna Type Chip
VSWR 2, 2.4
Number of Bands 2
Frequency Group UHF 2GHz~3GHz SHF f > 4GHz
Frequency (Center/Band) 2.4GHz 5.8GHz
Dimensions
Height (Max) 0.043 1.10mm
Compliance
RoHS Status RoHS Compliant
