WPD136M6B-001
RoHS
/
Package /
Category RF/IF and RFID / RF Antennas
Description
WHIP MC CC 136 380 760 MULTI BK
PDF
/
Inventory: 3662
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height (Max) 20.000 508.00mm
Height 508mm
Technical
Frequency (Center/Band) 155MHz 450MHz 815MHz
Frequency Group VHF f < 300MHz UHF 300MHz~1GHz
Number of Bands 3
VSWR 2.5
Antenna Type Whip, Straight
Frequency Range 136MHz~174MHz 380MHz~520MHz 760MHz~870MHz
Gain 0.2dBi, 4.8dBi, 8.1dBi
Power - Max 100W
Ingress Protection IP66
Max Power Dissipation 100W
Applications TETRA
Termination NMO
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2013
Packaging Bulk
Physical
Mounting Type Base Mount
Mount Base
Supply Chain
Factory Lead Time 4 Weeks
