P822602
RoHS
RoHS compliant
RoHS compliantPackage /
Category RF/IF and RFID / RF Antennas
Description
EMBEDDED LTE CELLULAR ANTENNA
PDF
/
Buying Options
Total Price: USD $3.12
Unit Price: USD $3.124
≥1 USD $3.124
≥10 USD $2.80456
≥100 USD $2.651264
≥500 USD $2.297768
≥1000 USD $2.179901
≥3000 USD $1.956029
Inventory: 1434
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Technical
Packaging Tape & Reel (TR)
Published 2018
Series Prestta?
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Applications CDMA, DCS, EDGE, GPRS, GSM, HSDPA, LTE, PCS, UMTS, WCDMA
Additional Feature IT CAN ALSO OPERATE AT 1710 TO 2200 MHZ AND 2500 TO 2700 MHZ
Construction COMPONENT
Reach Compliance Code unknown
Polarization LINEAR
Power - Max 2W
Gain 1.1dBi, 1.7dBi, 1.8dBi, 2.2dBi, 3.9dBi, 3.8dBi, 3.4dBi, 3.6dBi
Frequency Range 700MHz~787MHz 824MHz~960MHz 1.71GHz~2.17GHz 2.5GHz~2.7GHz
RF/Microwave Device Type MOBILE STATION ANTENNA
Operating Frequency-Max 960MHz
RF Family/Standard Cellular
Antenna Type Flat Bar
VSWR 2.5
Number of Bands 8
Frequency Group Wide B
Frequency (Center/Band) 700MHz 750MHz 850MHz 900MHz 1.8GHz 1.9GHz 2.1GHz 2.7GHz
Characteristic Impedance 50Ohm
Transmission Power-Max 2W
Dimensions
Height (Max) 0.126 3.20mm
Compliance
RoHS Status RoHS Compliant
