P522306
RoHS
RoHS compliant
RoHS compliantPackage /
Category RF/IF and RFID / RF Antennas
Description
RF ANT 850MHZ/900MHZ FLAT PATCH
PDF
/
Inventory: 6311
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Adhesive
Mounting Type Adhesive
Technical
Packaging Bulk
Series Prestta?
Feature Cable - 200mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination U.FL (UMCC), IPEX MHF1
Applications CDMA, DCS, GSM, PCS, UMTS, WCDMA
Max Power Dissipation 2W
Power - Max 2W
Gain 2.5dBi, 1.7dBi, 1.7dBi, 3.2dBi, 3.8dBi
Frequency Range 824MHz~960MHz 1.71GHz~2.17GHz
RF Family/Standard Cellular
Antenna Type Flat Patch
VSWR 3
Number of Bands 5
Frequency Group Wide B
Frequency (Center/Band) 850MHz 900MHz 1.8GHz 1.9GHz 2.1GHz
Dimensions
Height 1.2446mm
Height (Max) 0.049 1.25mm
Compliance
RoHS Status RoHS Compliant
