1020B5743-01
RoHS
RoHS compliant
RoHS compliantPackage /
Category RF/IF and RFID / RF Antennas
Description
ANTENNA 2.4GHZ SNAP-IN 0.8MM PCB
PDF
/
Inventory: 6223
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mount Snap in
Mounting Type Snap-In
Technical
Packaging Tray
Published 2006
Series Flavus
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMA Male
Applications Bluetooth, Wi-Fi, WiMedia?, Zigbee?
Frequency 2.5GHz
Impedance 50Ohm
Bandwidth 160MHz
Gain 4dBi
Max Frequency 2.5GHz
Frequency Range 2.4GHz~2.5GHz
RF Family/Standard 802.15.4, Bluetooth, WiFi
Antenna Type Molded
VSWR 1.5
Number of Bands 1
Frequency Group UHF 2GHz~3GHz
Frequency (Center/Band) 2.4GHz
Dimensions
Height 3.8354mm
Length 27.3mm
Width 7.9mm
Height (Max) 0.236 6.00mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
