AMCA52-2R780G-S1F-T
RoHS
RoHS compliant
RoHS compliantPackage SMD/SMT
Category RF/IF and RFID / RF Antennas
Description
Antennas 2.78GHz BW 200dB + Gain 0.5dBi avg.
PDF
/
Inventory: 3523
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height (Max) 0.039 1.00mm
Height 990.6μm
Technical
Frequency (Center/Band) 2.8GHz
Frequency Group UHF 2GHz~3GHz
Number of Bands 1
VSWR 2
Antenna Type Chip
RF Family/Standard WiFi
Frequency Range 2.68GHz~2.88GHz
Max Frequency 2.78GHz
Gain 2.5dBi
Bandwidth 200MHz
Power - Max 3W
Impedance 50Ohm
Frequency 2.78GHz
Max Power Dissipation 3W
Power Rating 3W
Applications WiMax?, WLAN
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Series AMCA
Published 2011
Packaging Tape & Reel (TR)
Physical
Package / Case SMD/SMT
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
