TSH690IDT image
Favorite
TSH690IDT image
Favorite
RoHS
RoHS RoHS compliant
Package 8-SOIC (0.154, 3.90mm Width)
Category RF/IF and RFID / RF Amplifiers
Description IC AMP 40MHZ - 1GHZ 8-SOIC
PDF
/
Inventory: 972
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Technical

P1dB 14.3dBm
Noise Figure 5.4dB
Characteristic Impedance 50Ohm
RF Type Cellular, GSM, TDMA
RF/Microwave Device Type WIDE BAND LOW POWER
Gain 30dB
Nominal Supply Current 105mA
Operating Supply Current 105mA
Test Frequency 900MHz
Number of Channels 1
Power Supplies 2.7V
Operating Supply Voltage 3V
Base Part Number TSH690
Frequency 40MHz~1GHz
Construction COMPONENT
Number of Functions 1
Voltage - Supply 1.5V~5V
Technology BIPOLAR
Subcategory RF/Microwave Amplifiers
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e4
Packaging Tape & Reel (TR)

Physical

Number of Pins 8
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
