SKY67130-396LF
RoHS
RoHS compliant
RoHS compliantPackage 8-WFDFN Exposed Pad
Category RF/IF and RFID / RF Amplifiers
Description
RF Amp Chip Single GP 2.7GHz 5V 8-Pin DFN EP T/R
PDF
/
Buying Options
Total Price: USD $2.42
Unit Price: USD $2.4168
≥1 USD $2.4168
≥10 USD $1.98265
≥100 USD $1.9209
≥500 USD $1.85915
≥1000 USD $1.7974
Inventory: 51007
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 2mm
Length 2mm
Technical
P1dB 16dBm
Noise Figure 2.6dB
RF Type General Purpose
Telecom IC Type RF AND BASEBAND CIRCUIT
Gain 13dB
Power Dissipation 150mW
Operating Supply Current 22mA
Test Frequency 2.7GHz
Number of Channels 1
Temperature Grade INDUSTRIAL
Operating Supply Voltage 3.3V
Frequency 700MHz~2.7GHz
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Number of Functions 1
Terminal Position DUAL
Voltage - Supply 5.5V
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2012
Packaging Cut Tape (CT)
Physical
Number of Pins 8
Package / Case 8-WFDFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
