SKY65013-70LF
RoHS
RoHS compliant
RoHS compliantPackage TO-243AA
Category RF/IF and RFID / RF Amplifiers
Description
RF Amplifier .1-1.7GHz InGaP HBT Sm Sig Gain 12.5dB
PDF
/
Buying Options
Total Price: USD $1.34
Unit Price: USD $1.34235
≥1 USD $1.34235
≥10 USD $1.102
≥100 USD $1.0678
≥500 USD $1.03265
≥1000 USD $0.99845
Inventory: 37438
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-243AA
Number of Pins 4
Technical
Packaging Tape & Reel (TR)
Published 2013
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Subcategory RF/Microwave Amplifiers
Max Power Dissipation 600mW
Number of Functions 1
Construction COMPONENT
Frequency 100MHz~7GHz
Operating Supply Voltage 3.5V
Number of Channels 1
Test Frequency 7GHz
Operating Supply Current 120mA
Nominal Supply Current 40mA
Power Dissipation 600mW
Max Supply Current 120mA
Gain 12.5dB
RF/Microwave Device Type WIDE BAND LOW POWER
VSWR-Max 2
RF Type WiMax, WLAN
Characteristic Impedance 50Ohm
Noise Figure 5.5dB
P1dB 12.5dBm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
