SE5022T-R
RoHS
/
Package 16-UFQFN Exposed Pad
Category RF/IF and RFID / RF Amplifiers
Description
802.11AC PA IN 3X3QFN
PDF
/
Buying Options
Total Price: USD $2.49
Unit Price: USD $2.489
≥1 USD $2.489
≥10 USD $2.0425
≥100 USD $1.97885
≥500 USD $1.91425
≥1000 USD $1.8506
Inventory: 3438
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 3mm
Length 3mm
Height Seated (Max) 0.6mm
Technical
P1dB 25dBm
RF Type 802.11a/n/ac
Telecom IC Type TELECOM CIRCUIT
Gain 32dB
Current - Supply 195mA
Test Frequency 5.15GHz~5.85GHz
Temperature Grade INDUSTRIAL
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
JESD-30 Code S-XQCC-N16
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 5.15GHz~5.85GHz
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 3V~3.6V
HTS Code 8542.39.00.01
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Tape & Reel (TR)
Physical
Surface Mount YES
Package / Case 16-UFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 23 Weeks
