SE2605L-R image
Favorite
SE2605L-R image
Favorite
RoHS
RoHS RoHS compliant
Package 16-VFQFN Exposed Pad
Category RF/IF and RFID / RF Amplifiers
Description RF Amplifier 2.4GHz 802.11bgn -40C +70C
PDF
/
Buying Options
Total Price: USD $0.97
Unit Price: USD $0.96805
≥1 USD $0.96805
≥10 USD $0.7942
≥100 USD $0.7695
≥500 USD $0.7448
≥1000 USD $0.7201
Inventory: 66803
Minimum: 1
-
+

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-VFQFN Exposed Pad
Number of Pins 16

Technical

Packaging Tape & Reel (TR)
Published 2012
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 16
Max Operating Temperature 70°C
Min Operating Temperature -40°C
Terminal Position QUAD
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.5mm
Frequency 2.4GHz~2.5GHz
Pin Count 16
Operating Supply Voltage 5V
Temperature Grade OTHER
Number of Channels 1
Test Frequency 2.45GHz
Nominal Supply Current 500mA
Current - Supply 650mA
Gain 33dB
Telecom IC Type TELECOM CIRCUIT
RF Type WLAN
P1dB 32dBm

Dimensions

Height Seated (Max) 0.9mm
Length 3mm
Width 3mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
