RFX242
RoHS
RoHS compliant
RoHS compliantPackage 16-UFQFN Exposed Pad
Category RF/IF and RFID / RF Amplifiers
Description
IC AMP 802.11A/B/G/ 2.4GHZ 16QFN
PDF
/
Buying Options
Total Price: USD $0.85
Unit Price: USD $0.8536
≥1 USD $0.8536
Inventory: 1348
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3mm
Length 3mm
Height Seated (Max) 0.65mm
Technical
P1dB 31dBm
RF Type 802.11a/b/g/n/ac
Telecom IC Type TELECOM CIRCUIT
Gain 32dB
Current - Supply 430mA
Test Frequency 2.4GHz
Temperature Grade INDUSTRIAL
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
JESD-30 Code S-XQCC-N16
Frequency 2.4GHz~2.5GHz
Reach Compliance Code unknown
Terminal Pitch 0.5mm
Supply Voltage 5V
Number of Functions 1
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 5V
Technology CMOS
HTS Code 8542.39.00.01
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2016
Packaging Tape & Reel (TR)
Physical
Surface Mount YES
Package / Case 16-UFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
