SGA-7489Z
RoHS
/
Package SOT-89-3
Category RF/IF and RFID / RF Amplifiers
Description
IC AMP HBT SIGE 3000MHZ SOT-89
PDF
/
Buying Options
Total Price: USD $6.71
Unit Price: USD $6.7127
≥1 USD $6.7127
≥10 USD $5.5081
≥100 USD $5.3352
≥500 USD $5.16325
≥1000 USD $4.9913
Inventory: 241
Minimum: 1
-
+
Technical Details
Physical
Package / Case SOT-89-3
Surface Mount YES
Mounting Feature SURFACE MOUNT
Technical
Published 2005
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Number of Terminations 3
Terminal Finish Matte Tin (Sn)
Subcategory RF/Microwave Amplifiers
Technology BIPOLAR
Number of Functions 1
Construction COMPONENT
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Power Supplies 5V
Test Frequency 1.95GHz
Operating Supply Current 127mA
Gain 20 dB
RF/Microwave Device Type WIDE BAND LOW POWER
Operating Frequency-Max 3000MHz
VSWR-Max 10
Input Power-Max (CW) 16dBm
Characteristic Impedance 50Ohm
Noise Figure 4.3 dB
P1dB 20 dBm
Compliance
RoHS Status RoHS Compliant
