SGA-4386Z
RoHS
/
Package SOT-86
Category RF/IF and RFID / RF Amplifiers
Description
IC AMP HBT SIGE 4500MHZ SOT-86
PDF
/
Inventory: 4174
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case SOT-86
Surface Mount YES
Mounting Feature SURFACE MOUNT
Technical
Published 2008
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Number of Terminations 4
Terminal Finish Matte Tin (Sn)
Subcategory RF/Microwave Amplifiers
Technology BIPOLAR
Number of Functions 1
Construction COMPONENT
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Power Supplies 3.2V
Test Frequency 1.95GHz
Operating Supply Current 49mA
Gain 14.6 dB
RF/Microwave Device Type WIDE BAND LOW POWER
Operating Frequency-Max 4500MHz
Input Power-Max (CW) 18dBm
Characteristic Impedance 50Ohm
Noise Figure 3.1 dB
P1dB 13 dBm
Compliance
RoHS Status RoHS Compliant
