SGA-2386
RoHS
/
Package SOT-86
Category RF/IF and RFID / RF Amplifiers
Description
IC AMP CELLULAR 0HZ-5GHZ SOT86
PDF
/
Buying Options
Total Price: USD $2.21
Unit Price: USD $2.21255
≥1 USD $2.21255
≥10 USD $1.81545
≥100 USD $1.75845
≥500 USD $1.70145
≥1000 USD $1.6454
Inventory: 2385
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
P1dB 7.5dBm
Noise Figure 3.2dB
Characteristic Impedance 50Ohm
Input Power-Max (CW) 18dBm
RF Type Cellular, GSM, PCS, UMTS
RF/Microwave Device Type WIDE BAND LOW POWER
Gain 15.3dB
Current - Supply 17mA~23mA
Test Frequency 1.95GHz
Power Supplies 2.7V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Frequency 0Hz~5GHz
Construction COMPONENT
Number of Functions 1
Voltage - Supply 2.4V~3V
Technology BIPOLAR
Subcategory RF/Microwave Amplifiers
Terminal Finish Tin/Lead (Sn/Pb)
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Published 2010
Packaging Tape & Reel (TR)
Physical
Surface Mount YES
Package / Case SOT-86
Mounting Type Surface Mount
