SGA-2363Z
RoHS
/
Package SOT-363
Category RF/IF and RFID / RF Amplifiers
Description
IC AMP HBT SIGE 5000MHZ SOT-363
PDF
/
Buying Options
Total Price: USD $14.77
Unit Price: USD $14.7668
≥1 USD $14.7668
≥10 USD $12.1163
≥100 USD $11.7382
≥500 USD $11.35915
≥1000 USD $10.9801
Inventory: 147
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
P1dB 7.2 dBm
Noise Figure 3.2 dB
Characteristic Impedance 50Ohm
Input Power-Max (CW) 18dBm
Operating Frequency-Max 5000MHz
RF/Microwave Device Type WIDE BAND LOW POWER
Gain 16.1 dB
Operating Supply Current 23mA
Test Frequency 1.95GHz
Power Supplies 2.7V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Reach Compliance Code unknown
Construction COMPONENT
Number of Functions 1
Technology BIPOLAR
Subcategory RF/Microwave Amplifiers
Terminal Finish Matte Tin (Sn)
Number of Terminations 6
Pbfree Code yes
JESD-609 Code e3
Published 2011
Physical
Mounting Feature SURFACE MOUNT
Surface Mount YES
Package / Case SOT-363
