SMA3103-TL-E
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD, Flat Leads
Category RF/IF and RFID / RF Amplifiers
Description
RF Amp Chip Single GP 3.3GHz 5.5V 6-Pin MCPH T/R
PDF
/
Buying Options
Total Price: USD $0.34
Unit Price: USD $0.3432
≥1 USD $0.3432
≥10 USD $0.30536
≥100 USD $0.275616
≥500 USD $0.241032
≥1000 USD $0.211552
≥3000 USD $0.186947
Inventory: 3008
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 1.6mm
Length 2mm
Height 850μm
Technical
P1dB 5.7dBm
Noise Figure 4.7dB
RF Type General Purpose
RF/Microwave Device Type WIDE BAND LOW POWER
Gain 27dB
Power Dissipation 280mW
Nominal Supply Current 19mA
Operating Supply Current 19mA
Test Frequency 2.2GHz
Number of Channels 1
Operating Supply Voltage 5V
Pin Count 6
Frequency 0Hz~2.2GHz
Voltage - Supply 4.5V~5.5V
Max Power Dissipation 280mW
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin/Bismuth (Sn/Bi)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e6
Published 2009
Packaging Tape & Reel (TR)
Physical
Number of Pins 6
Package / Case 6-SMD, Flat Leads
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 4 Weeks
