BGA7204,515
RoHS
/
Package /
Category RF/IF and RFID / RF Amplifiers
Description
RF Amp Chip Single GP 2.75GHz 5.25V 32-Pin HVQFN EP T/R
PDF
/
Inventory: 5810
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Gold
Mount Surface Mount
Number of Pins 32
Technical
Packaging Digi-Reel?
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Frequency 400MHz
Pin Count 32
Operating Supply Voltage 5V
Number of Channels 1
Max Supply Voltage 5.25V
Min Supply Voltage 4.75V
Test Frequency 2.1GHz
Operating Supply Current 133mA
Nominal Supply Current 133mA
Max Supply Current 133mA
Frequency (Max) 2.75GHz
Gain 16.5 dB
Noise Figure 10 dB
P1dB 20.5 dBm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
