SST12LP14-QVCE
RoHS
RoHS compliant
RoHS compliantPackage 16-VFQFN Exposed Pad
Category RF/IF and RFID / RF Amplifiers
Description
RF Amp Chip Single Power Amp 2.485GHz 4.2V 16-Pin VQFN
PDF
/
Buying Options
Total Price: USD $0.94
Unit Price: USD $0.9416
≥1 USD $0.9416
≥10 USD $0.7832
≥100 USD $0.6776
Inventory: 2842
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Package / Case 16-VFQFN Exposed Pad
Surface Mount YES
Number of Pins 16
Technical
Packaging Tape & Reel (TR)
Published 2000
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Additional Feature HIGH RELIABILITY
Subcategory RF/Microwave Amplifiers
Voltage - Supply 3V~4.2V
Number of Functions 1
Construction COMPONENT
Frequency 2.4GHz~2.485GHz
Operating Supply Voltage 3.3V
Number of Channels 1
Test Frequency 2.4GHz~2.485GHz
Operating Supply Current 340mA
Nominal Supply Current 340mA
Max Supply Current 340mA
Gain 31dB
RF/Microwave Device Type NARROW BAND MEDIUM POWER
RF Type 802.11g
Characteristic Impedance 50Ohm
P1dB 26.5dBm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
