SST12CP12-QUCE

Microchip Technology
RoHS
RoHS RoHS compliant
Package 16-UFQFN Exposed Pad
Category RF/IF and RFID / RF Amplifiers
Description IC AMP 802.11B/G/N 2.4GHZ 16UQFN
PDF
/
Inventory: 3228
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No

Technical

Characteristic Impedance 50Ohm
Input Power-Max (CW) 5dBm
RF Type 802.11b/g/n
VSWR-Max 10
RF/Microwave Device Type NARROW BAND MEDIUM POWER
Gain 33dB
Nominal Supply Current 600mA
Operating Supply Current 670mA
Test Frequency 2.4GHz~2.5GHz
Number of Channels 1
Power Supplies 5V
Operating Supply Voltage 5V
Frequency 2.4GHz~2.5GHz
Construction COMPONENT
Number of Functions 1
Voltage - Supply 3V~5V
Technology BIPOLAR
Subcategory RF/Microwave Amplifiers
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Matte Tin (Sn)
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 2000
Packaging Tape & Reel (TR)

Physical

Number of Pins 16
Package / Case 16-UFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
