SC1894A-00C13E
RoHS
RoHS compliant
RoHS compliantPackage 64-VFQFN Exposed Pad
Category RF/IF and RFID / RF Amplifiers
Description
RF Amp Chip Power Amp 3800MHz 1.9V/3.5V 64-Pin QFN T/R
PDF
/
Buying Options
Total Price: USD $66.09
Unit Price: USD $66.0877
≥1 USD $66.0877
≥10 USD $64.0224
≥100 USD $61.9571
≥500 USD $59.8918
≥1000 USD $53.6959
Inventory: 1143
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 9mm
Length 9mm
Height Seated (Max) 0.9mm
Technical
RF Type Cellular, DVB-H, HSDPA, ISDB-T, LTE, TD-LTE, TD-SCDMA, WiMAX, W-CDMA
Telecom IC Type TELECOM CIRCUIT
Current - Supply 100mA 840mA
Test Frequency 225MHz~3.8GHz
JESD-30 Code S-XQCC-N64
Base Part Number SC1894
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 225MHz~3.8GHz
Terminal Pitch 0.5mm
Supply Voltage 1.8V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 1.7V~1.9V 3.1V~3.5V
Max Power Dissipation 1.4W
HTS Code 8542.39.00.01
Number of Terminations 64
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2013
Packaging Tape & Reel (TR)
Physical
Surface Mount YES
Package / Case 64-VFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
