MSA-1105-TR1G
RoHS
RoHS compliant
RoHS compliantPackage 4-SMD (05 Plastic)
Category RF/IF and RFID / RF Amplifiers
Description
IC AMP ISM 50MHZ-1.3GHZ 05 PLAST
PDF
/
Buying Options
Total Price: USD $3.22
Unit Price: USD $3.2224
≥1 USD $3.2224
≥10 USD $2.64385
≥100 USD $2.5612
≥500 USD $2.47855
≥1000 USD $2.3959
Inventory: 29708
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 4-SMD (05 Plastic)
Surface Mount YES
Technical
Packaging Tape & Reel (TR)
Published 2005
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Additional Feature HIGH RELIABILITY
HTS Code 8542.33.00.01
Subcategory RF/Microwave Amplifiers
Technology BIPOLAR
Voltage - Supply 4.4V~6.6V
Number of Functions 1
Construction COMPONENT
Reach Compliance Code unknown
Frequency 50MHz~1.3GHz
Power Supplies 5.5V
Test Frequency 500MHz
Current - Supply 80mA
Gain 10dB ~ 12dB
RF/Microwave Device Type WIDE BAND LOW POWER
VSWR-Max 1.7
RF Type ISM, PCS, WLL, 802.16/WiMax
Input Power-Max (CW) 13dBm
Characteristic Impedance 50Ohm
Noise Figure 3.6dB
P1dB 17.5dBm
Compliance
RoHS Status RoHS Compliant
